| Modelis |
UTP3-GSW1604TS-P200 |
| Downstream jungtys |
16* 10/100/1000Base-T(16 Ports PoE) |
| Uplink jungtys |
2*10/100/1000Base-T and 2*1000Base-X(SFP) |
| Tinklo standartai |
IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE802.3X |
| Pajėgumas |
40/56/56Gbps |
| Pralaidumas |
28/42/42Mpps |
| Veikimas |
Store and Forward |
| Atminties buferis |
4M |
| MAC lentelė |
8K |
| PoE Standartai |
802.3af/at(PSE) |
| PsE Tipas |
End-span |
| Pajungimas |
1/2(+)，3/6(-) |
| PoE maitinimo išvestis |
54V DC, 30 watts max |
| PoE suvartojimas |
170 watts max |
| Veikimo rėžimas |
Default:All ports can communicate with each other |
| VLAN: 1. Downlink ports only communicate with uplink ports; |
| 2. Restrain network storm under 2Mbps |
| Flow control:Switch flow control function is turned off, this mode is suitable for video surveillance transmission |
| Apsauga nuo žaibo |
6KV Execute：IEC61000-4-5 |
| ESD |
6KV Contact discharge |
| 8KV Air discharge |
| Execute: IEC61000-4-2 |
| Maitinimas |
100~240V AC?50/60Hz |
| Energijos suvartojimas |
＜200W(Including PoE) |
| Veikimo temperatūra |
0℃~40℃ |
| Santykinis oro drėgnumas |
5%-95% |
| Išmatavimai |
442mm×285mm×44.5mm |
| Svoris |
3kg |
| Sertifikatai |
CE, FCC, ROHS |
