| Pavadinimas |
Aprašymas |
| Kodavimo raiška |
Main stream: When 1080p lite mode not enabled: For 4 MP stream access: 4 MP lite@15 fps; 1080p lite/720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N) For 3 MP stream access: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF@15 fps For 1080p stream access: 1080p/720p@15 fps; VGA/WD1/4CIF/CIF@25 fps (P)/30 fps (N) For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25 fps (P)/30 fps (N) When 1080p Lite mode enabled: 4 MP lite/3 MP@15 fps; 1080p lite/720p lite/VGA/WD1/4CIF/CIF@25 fps (P)/30 fps (N) Sub-stream: WD1/4CIF@12 fps; CIF@25 fps (P)/30 fps (N) |
| Vaizdo bitų greitis |
32 Kbps to 6 Mbps |
| Vaizdo suspaudimas |
H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 |
| Dvigubas srautas |
Support |
| Srauto tipas |
Video, Video & Audio |
| Garso suspaudimas |
G.711u |
| Garso bitų greitis |
64 Kbps |
| Garso įvestis |
1-ch, RCA (2.0 Vp-p, 1 KΩ) |
| Garso išvestis |
1-ch, RCA (Linear, 1 KΩ) |
| Sinchroninis atkūrimas |
4-ch |
| IP vaizdo išvestis |
2-ch (up to 6-ch);Up to 6 MP resolution;Support H.265+/H.265/H.264+/H.264 IP cameras |
| HDTVI įvestis |
3 MP, 1080p@30 fps, 1080p@25 fps, 720p@60 fps, 720p@50 fps, 720p@30 fps, 720p@25 fps *: The 3 MP signal input is only available for channel 1/2 of iDS-7208HQHI-M2/S, and for channel 1/2/3/4 of iDS-7216HQHI-M2/S. |
| HDTVI įvestis |
4 MP, 1080p@25 fps, 1080p@30 fps, 720p@25 fps, 720p@30 fps |
| CVBS įvestis |
PAL/NTSC |
| Abipusis garso ryšys |
1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input) |
| Analoginė vaizdo įvestis |
4-ch;BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection |
| AHD įvestis |
4 MP, 1080p@25 fps, 1080p@30 fps, 720p@25 fps, 720p@30 fps |
| CVBS įvestis |
1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480 |
| HDMI/VGA išvestis |
1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz, HDMI/VGA simultaneous output |
| Tinklo protokolas |
TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF |
| Nuotolinis prisijungimas |
32 |
| Tinklo sąsaja |
1, RJ45 10M/100M self-adaptive Ethernet interface |
| Talpa |
Up to 10 TB capacity for each disk |
| Serijinė sąsaja |
RS-485 (half-duplex) |
| USB sąsaja |
2 × USB 2.0 |
| Pavojaus signalo įvestis/išvestis |
N/A |
| SATA |
1 SATA interface |
| Suvartojimas (be HDD) |
≤ 18 W |
| Darbinė drėgmė |
10% to 90% |
| Maitinimas |
12 VDC |
| Darbo temperatūra |
-10 °C to +55 °C (+14 °F to +131 °F) |
| Matmenys (P × G × A) |
315 × 242 × 45 mm (12.4 × 9.5 × 1.8 inch) |
| Svoris (be HDD) |
≤ 1.16 kg (2.6 lb) |
