Prekės aprašymas
Power Supply |
Power Adaptor |
Voltage Range |
DC 48V～54V |
Power Consumption |
<5W |
Speed |
1~8 port: Default: 10/100Mbps; CCTV: 10Mbps; UPLINK: 100Mbps |
Transmission Distance |
1~8 Ports: 0～100m (Default),CCTV: 0-250m,Uplink: 0-100m |
Ethernet Standard |
IEEE 802.3/802.3u/IEEE802.3 af/IEEE802.3at |
Exchange Capacity |
1.8Gbps |
Packet Forwarding Rate |
1.34 Mbps |
MAC |
2K |
Power Light |
1pcs (Red) |
Ethernet Port Light |
2pcs (Yellow& Green) on RJ45, Yellow Indicates PoE, Green Indicates Link/Act |
Surveillance Mode light |
1pcs(Green), Green Indicates CCTV Mode is initiated |
ESD |
Level 3 Per: IEC6 1 000-4-2 |
Operation Temperature |
-10℃～55℃ |
Storage Temperature |
-40℃～85℃ |
Humidity(non-condensing) |
0～95% |
Dimensions(LxWxH) |
200mm×101.8mm×27mm |
Color |
Black |
Weight |
500g |
