| Modelis |
UTP7108E-POE |
| Downstream jungtys |
8* 10/100Base-TX PoE RJ45 |
| Uplink jungtys |
1*1000Base-X SFP Port and 1*10/100/1000Base-T RJ45 Port |
| Tinklo standartai |
IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, EEE802.3 X |
| Switch Fabric |
5.6Gbps |
| Pajėgumas |
4Mpps |
| Veikimas |
Store and Forward |
| Atminties buferis |
1M |
| MAC lentelė |
8K |
| CCTV rėžimas |
1. Realize VLAN： 1～8 downlink PoE ports communicate with uplink ports only; 2. Extend the POE Ports transmission distance up to 250m (Max distance will depend on the camera and cable), but the downlink bandwidth only 10Mbps; 3.PoE watchdog ( Detect POE device when it is frozen, reboot automatically)
|
| PoE standartas |
802.3af/at |
| PsE tipas |
End-span |
| Power Pin priskyrimas |
1/2(+)?3/6(-) |
| PoE maitinimo išvestis |
48~57V DC , 30 watts max |
| PoE Budge |
240 watts max(Default power supply: 120W) |
| Apsaugo nuo žaibo |
6KV Execute：IEC61000-4-5
|
| ESD |
6KV Contact discharge |
| 8KV Air discharge |
|
Execute：IEC61000-4-2
|
| Maitinimas |
DC 48~57V |
| Maitinimo eikvojimas |
＜6W
|
| Veikimo temperatūra |
-30℃~65℃
|
| Santykinis oro drėgnumas(Non-condensin) |
5%-95% |
| Išmatavimai(L×W×H) |
159mm×110mm×44mm |
| Svoris |
500g |
| Reguliavimas |
CE、FCC、ROHS
|
