Jeweller ryšio technologijaProprietary wireless communication technology to transmit commands, alarms, and events., Key features:, Two-way communication., Advanced sabotage protection., Block encryption featuring a dynamic key., Instant notifications., Remote control and configuration in Ajax apps., Learn more
Dažnių juostos866.0–866.5 MHz 868.0–868.6 MHz 868.7–869.2 MHz 905.0–926.5 MHz * 915.85–926.5 MHz 921.0–922.0 MHz, Depends on the sales region., * Certified according to UL/ULC standards.
Maksimali efektyvi spinduliuojama galia (ERP)up to 20 mW, Automatic power control to reduce power consumption and radio interference.
Radijo signalo moduliacijaGFSK
Radijo ryšio veikimo nuotolisup to 3,900 ft, Between the device and a hub (or a range extender) in an open space., Calculate radio communication range at the facility
Šifruotas ryšysAll stored and transmitted data are protected by block encryption featuring a dynamic key.
Dažnių šuoliaiTo prevent radio interference and jamming., Learn more
Aptikimas
Jautrusis elementasPIR sensor, microwave sensor, K-band microwave sensor to prevent false alarms caused by thermal interference. Operation frequency: 24 GHz.
Judėjimo aptikimo atstumasup to 39 ft, When installed at the height of 7.9 ft.
Motion detection anglehorizontal: 88.5°
Judėjimo aptikimo greitisfrom 1 to 6.6 ft/s, The direction of the detector lens should be perpendicular to an alleged intrusion path into the facility.
Jautrumas3 levels, Adjusted by a PRO or a user with admin rights in the Ajax app.
Atsparumas naminių gyvūnų sukeltiems signalamsweight: up to 44 lb height: up to 1.6 ft, Learn more
Netikro pavojaus signalo prevencijaSmartDetect, Software algorithm., Learn more
Temperatūros kompensacijaEffective motion detection at temperatures from 14 °F to 104 °F., Learn more
Apsauga nuo sabotažo
Sabotažo signalasNotifications on attempts to detach the detector from the surface or remove it from the mounting panel., Learn more
Apsauga nuo klastojimodevice authentication
Ryšio praradimo aptikimasafter 36 s, Detection time depends on the Jeweller or Jeweller/Fibra settings., Learn more
