Ajax įrenginiaiup to 100, Specifically, up to 10 sirens or keypads with a built-in siren and 5 range extenders., More about devices
Ajax NVR įrenginiaiup to 14, Learn more
Ajax kamerosup to 224 via Ajax NVRs and up to 200 standalone, Learn more
Trečiųjų šalių IP kamerosup to 25 when using RTSP via SDK, up to 224 when using ONVIF via Ajax NVRs, Learn more
Vartotojaiup to 50, Any number of admin users within the hub limit., PRO accounts for installers., PRO accounts for installation and monitoring companies., Access management for users.
Automatizavimo scenarijaiup to 32, Alarm responses., Scheduled actions., Security mode changing reactions., Temperature changing reactions., Humidity changing reactions., Reactions to changes in CO₂ concentration., Reactions to pressing Button., Learn more
Saugumo grupėsup to 9, Learn more
Patalposup to 50
Įvykių žurnalasup to 1000 events, Events are saved on the non-volatile onboard flash memory.
Bendravimas
Jeweller ryšio technologijaProprietary wireless communication technology to transmit commands, alarms, and events., Key features:, Two-way communication., Advanced anti-sabotage., Block encryption featuring a dynamic key., Instant notifications., Remote control and configuration in Ajax apps., Learn more
Dažnių juostos866.0–866.5 MHz 868.0–868.6 MHz 868.7–869.2 MHz 905.0–926.5 MHz 915.85–926.5 MHz 921.0–922.0 MHz, Depends on the sales region.
Maksimali efektyvi spinduliuojama galia (ERP)up to 20 mW, Automatic power control to reduce power consumption and radio interference.
Radijo signalo moduliacijaGFSK
Radijo ryšio veikimo nuotolisup to 6,550 ft, Between a hub and connected devices (in an open space). Maximum range depends on the connected device., Learn more
Apklausos intervalasfrom 12 to 300 s, Adjusted by PRO or user with admin rights in the Ajax apps.
Šifruotas ryšysAll stored and transmitted data are protected by block encryption featuring a dynamic key.
Dažnių šuoliaiTo prevent radio interference and jamming., Learn more
Wings ryšio technologijaProprietary wireless communication technology to transmit photo verifications., Key features:, Two-way communication., Advanced anti-sabotage., Block encryption featuring a dynamic key., Data packages reload in case of transmission errors., Photo delivery check.
Dažnių juostos866.0–866.5 MHz 868.0–868.6 MHz 868.7–869.2 MHz 905.0–926.5 MHz 915.85–926.5 MHz 921.0–922.0 MHz, Depends on the sales region.
Maksimali efektyvi spinduliuojama galia (ERP)up to 20 mW, Automatic power control to reduce power consumption and radio interference.
Radijo ryšio veikimo nuotolisup to 5,550 ft, Between the hub and connected devices (in an open space). Maximum range depends on the connected device., Learn more
Šifruotas ryšysAll stored and transmitted data are protected by block encryption featuring a dynamic key.
Dažnių šuoliaiTo prevent radio interference and jamming., Learn more
Ryšio kanalai
Ethernet1 8P8C socket, Up to 100 Mbps.
Mobilusis ryšys2 micro-SIM slots
Mobiliojo ryšio dažnių juostos2G, GSM900/DCS1800 (B3/B8)
Automatinis perjungimas tarp ryšio kanalųBetween Ethernet and SIM — instantly., Between SIMs — up to 4 minutes.
Ryšio kanalų prioritetų nustatymas1. Ethernet 2. Cellular connection, Communication channels work in parallel to increase the system’s reliability. Most of the data is transmitted via Ethernet.
Signalizacijos perdavimo sistemų kategorijosSP2, SP5, DP3
Valdymo pulto veikimo būdasPass-through
Signalo saugumasS2, Substitution security.
Informacijos saugumasI2
Pranešimai
Pranešimų tipaiPush notifications, SMS, Calls, Learn more
Įvykių tipaiAlarms, Malfunctions, Security mode change, System events, Notification types are configured individually for each user. Notifications can be customized for A–D schemes according to EN 50131 requirements.
Nuotraukų patikra
Nuotraukų patikros tipaiPhoto by alarm, Photo by scenario, Photo on demand, Photo by schedule, The Photo by Schedule feature is available for hubs with firmware version OS Malevich 2.19 or higher., More about photo by scenario, More about photo on demand, More about photo by schedule
Nuotraukos pristatymo laikasup to 9 s, by default., Learn more
Nuotraukos raiškaup to 640 × 480 pixels, Depends on the detector.
Nuotraukų skaičius serijojefrom 1 to 5 pictures
Stebėjimas
Palaikomi protokolaiSIA (DC-09), SurGard (Contact ID), ADEMCO 685, Other proprietary protocols, Learn more
Įvykių tipaiSystem alarms and events, Panic button coordinates, Photo verification, Learn more
Maitinimas
Pagrindinis maitinimo šaltinio tipastype A
Įrenginio darbinės AC įtampos diapazonas110–240 V~, 50/60 Hz, Up to 10 W of mains power consumption.
Įrenginio darbinės DC įtampos diapazonas3.55–4.2 V⎓, Built-in rechargeable battery Li-ion 2 Аh., The hub manufactured after October 7, 2022 , has a 3-pin battery. If the hub was manufactured earlier, the battery can be a 2-pin or 3-pin one. To find out the battery type, contact Ajax Technical Support or check it manually., Learn more
Autonominis veikimasup to 15 hours, When Ethernet is disabled. The Battery Power Saver feature allows extending the backup battery life., Learn more
Alternatyva6 V⎓, Connected via an alternative power supply unit 6V PSU (type A) which is sold separately ., 12–24 V⎓, Connected via an alternative power supply unit 12–24V PSU (type A) which is sold separately ., Learn more
Apsauga nuo sabotažo
Sabotažo signalasNotifications on attempts to detach the device from the surface or remove it from the mounting panel., Learn more
Apsauga nuo klastojimodevice authentication
Dažnių šuoliaiThe hub sends notifications to all users and the security company about jamming or losing connection with the devices., Learn more
Korpusas
Matmenys6.42″ × 6.42″ × 1.42″
Svoris12.77 oz
Darbinė temperatūros ribafrom 14 °F to 104 °F
Drėgmėup to 75%
Apsaugos klasėIP20
