| Obejktyvas |
2.8 mm, 3.6 mm, 6 mm fixed lens |
| Horizontalus matymo laukas |
102.2° (2.8 mm), 79° (3.6 mm), 50.8° (6 mm) |
| Objektyvo montavimas |
M16 |
| DIena ir naktis |
IR cut filter |
| Sinchronizacija |
Internal synchronization |
| Kampo valdymas |
Pan: 0° to 360°, Tilt:0° to 75°, Rotate: 0° to 360° |
| Sensorius |
5 MP CMOS |
| SIgnalo sistema |
PAL/NTSC |
| Kadrų skaičius |
TVI: 5MP@20fps, 4MP@30fps, 4MP@25fps, 1080P@30fps, 1080P@25fps CVI: 4MP@30fps, 4MP@25fps AHD: 5MP@20fps, 4MP@30fps, 4MP@25fps CVBS: PAL/NTSC |
| Raiška |
2560(H) × 1944 (V) |
| Min. apšvietimas |
Color: 0.01 Lux@(F1.2, AGC ON), 0 Lux with IR |
| Užrakto laikas |
PAL: 1/12.5 s to 1/50,000 s NTSC: 1/15 s to 1/50,000 s |
| AGC |
Yes |
| Diena/naktis režimas |
Auto/Color/BW (Black and White) |
| Baltos spalvos balansas |
Auto/Manual |
| Pašvietimo kompensavimas |
Yes |
| DWDR |
105 dB |
| Kalba |
English |
| Funkcijos |
Brightness, Sharpness, DNR, Mirror, Smart IR, HLC |
| Vaizdo išvestis |
1 HD analog output |
| Perjungimo mygtukas |
TVI/AHD/CVI/CVBS |
| Darbo sąlygos |
-40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation) |
| Maitinimas |
12 VDC ±25% *You are recommended to use one power adapter to supply the power for one camera. |
| Suvartojimas |
Max. 5.3 W |
| Medžiaga |
Plastic |
| IR atstumas |
Up to 20 m |
| Ryšiai |
Up the coax, Protocol: HIKVISION-C (TVI output) |
| Matmenys |
Ø 70 mm × 159.8 mm (Ø 2.76" × 6.29" ) |
| Svoris |
Approx. 180 g (0.40 lb.) |
