Mobilus modulis4G LTE Cat 6 up to 300 DL/ 50 UL Mbps; 3G up to 42 DL/ 5.76 UL Mbps
3GPP išleidimasRelease 12
SIM switch2 SIM cards, auto-switch cases: weak signal, data limit, SMS limit, roaming, no network, network denied, data connection fail, SIM idle protection
StatusasIMSI, ICCID, operator, operator state, data connection state, network type, CA indicator, bandwidth, connected band, signal strength (RSSI), SINR, RSRP, RSRQ, EC/IO, RSCP, data sent/received, LAC, TAC, cell ID, ARFCN, UARFCN, EARFCN, MCC, and MNC
SMSSMS status, SMS configuration, send/read SMS via HTTP POST/GET, EMAIL to SMS, SMS to EMAIL, SMS to HTTP, SMS to SMS, scheduled SMS, SMS autoreply, SMPP
USSDSupports sending and reading Unstructured Supplementary Service Data messages
Block/Allow listOperator block/allow list (by country or separate operators)
Multiple PDNPossibility to use different PDNs for multiple network access and services
Grupės valdymasBand lock, Used band status display
SIM neaktyvumo apsaugos paslaugaProvides the possibility to configure the router to periodically switch to the unused SIM card and establish a data connection in order to prevent the SIM card from being blocked
SIM PIN kodo valdymasSIM PIN code management enables setting, changing, or disabling the SIM card's PIN
APNAuto APN
TiltasDirect connection (bridge) between mobile ISP and device on LAN
PerleidimasRouter assigns its mobile WAN IP address to another device on LAN
Bevielis ryšys
Belaidžio ryšio režimas802.11b/g/n/ac Wave 2 (Wi-Fi 5) with data transmission rates up to 867 Mbps (Dual Band, MU-MIMO)
Ugniasienės būsenos puslapisView all your Firewall statistics, rules, and rule counters
Prievadų valdymasView device ports, enable and disable each of them, turn auto-configuration on or off, change their transmission speed, and so on
Tinklo topologijaVisual representation of your network, showing which devices are connected to which other devices
DHCPStatic and dynamic IP allocation, DHCP relay, DHCP server configuration, status, static leases: MAC with wildcards
QoS / išmanusis eilių valdymas (SQM)Traffic priority queuing by source/destination, service, protocol or port, WMM, 802.11e
DDNSSupported >25 service providers, others can be configured manually
DNS per HTTPSDNS over HTTPS proxy enables secure DNS resolution by routing DNS queries over HTTPS
Tinklo atsarginės kopijosWi-Fi WAN, Mobile, VRRP, Wired options, each of which can be used as an automatic Failover
Apkrovos balansavimasBalance Internet traffic over multiple WAN connections
Viešosios interneto prieigos taškasCaptive portal (hotspot), internal/external Radius server, Radius MAC authentication, SMS authorisation, SSO authentication, internal/external landing page, walled garden, user scripts, URL parameters, user groups, individual user or group limitations, user management, 9 default customisable themes and optionality to upload and download customised hotspot themes
SSHFSPossibility to mount remote file system via SSH protocol
VRF supportInitial virtual routing and forwarding (VRF) support
Eismo valdymasReal-time monitoring, wireless signal charts, traffic usage history
Saugumas
802.1xPort-based network access control client
AutentifikavimasPre-shared key, digital certificates, X.509 certificates, TACACS+, Internal & External RADIUS users authentication, IP & login attempts block, time-based login blocking, built-in random password generator
UgniasienėPreconfigured firewall rules can be enabled via WebUI, unlimited firewall configuration via CLI, DMZ, NAT, NAT-T, NAT64
PPTP, L2TPClient/Server instances can run simultaneously, L2TPv3, L2TP over IPsec support
StunnelProxy designed to add TLS encryption functionality to existing clients and servers without any changes in the program’s code
DMVPNMethod of building scalable IPsec VPNs, Phase 2 and Phase 3 and Dual Hub support
SSTPSSTP client instance support
ZeroTierZeroTier VPN client support
WireGuardWireGuard VPN client and server support
TincTinc offers encryption, authentication and compression in it's tunnels. Client and server support.
TailscaleTailscale offers speed, stability, and simplicity over traditional VPNs. Encrypted point-to-point connections using the open source WireGuard protocol
OPC UA
Palaikomi režimaiClient, Server
Supported connection typesTCP
MODBUS
Palaikomi režimaiServer, Client
Supported connection typesTCP, USB
Pasirinktiniai registraiMODBUS TCP custom register block requests, which read/write to a file inside the router, and can be used to extend MODBUS TCP Client functionality
Data to serverExtract parameters from multiple sources and different protocols, and send them all to a single server; Custom LUA scripting, allowing scripts to utilize the router's Data to server feature
MQTT Gateway
Modbus MQTT GatewayAllows sending commands and receiving data from MODBUS Server through MQTT broker
DNP3
Palaikomi režimaiStation, Outstation
Supported connectionTCP, USB
DLMS
DLMS SupportDLMS - standard protocol for utility meter data exchange
Palaikomi režimaiClient
Supported connection typesTCP, USB
COSEMAllows to scan meter COSEM objects for automatic detection and configuration
API
Teltonika Networks Web API (beta) supportExpand your device's possibilities by using a set of configurable API endpoints to retrieve or change data. For more information, please refer to this documentation: https://developers.teltonika-networks.com
Monitoring & Management
WEB UIHTTP/HTTPS, status, configuration, FW update, CLI, troubleshoot, multiple event log servers, firmware update availability notifications, event log, system log, kernel log, Internet status
FOTAFirmware update from server, automatic notification
SSHSSH (v1, v2)
SMSSMS status, SMS configuration, send/read SMS via HTTP POST/GET
CallReboot, Status, Mobile data on/off, Output on/off, answer/hang-up with a timer
El. paštasReceive email message status alerts of various services
SNMPSNMP (v1, v2, v3), SNMP Trap, Brute force protection
RMSTeltonika Remote Management System (RMS)
IoT platformos
ThingWorxAllows monitoring of: WAN Type, WAN IP, Mobile Operator Name, Mobile Signal Strength, Mobile Network Type
Cumulocity - Cloud of ThingsAllows monitoring of: Device Model, Revision and Serial Number, WAN Type and IP, Mobile Cell ID, ICCID, IMEI, Connection Type, Operator, Signal Strength. Has reboot and firmware upgrade actions
Azure IoT HubCan be configured with Data to Server to send all the available parameters to the cloud. Has Direct method support which allows to execute RutOS API calls on the IoT Hub. Also has Plug and Play integration with Device Provisioning Service that allows zero-touch device provisioning to IoT Hubs
AWS IoT CoreUtility to interact with the AWS cloud platform. Jobs Support: Call the device's API using AWS Jobs functionality
FLASH saugykla16 MB serial NOR flash, 256 MB serial NAND flash
Nustatymai
WEB UIUpdate FW from file, check FW on server, configuration profiles, configuration backup
FOTAUpdate FW
RMSUpdate FW/configuration for multiple devices at once
Nustatymų įsiminimasUpdate FW without losing current configuration
Factory settings resetA full factory reset restores all system settings, including the IP address, PIN, and user data to the default manufacturer's configuration
FIRMWARE CUSTOMISATION
Operacinė sistemaRutOS (OpenWrt based Linux OS)
KalbosBusybox shell, Lua, C, C++
Kūrėjo įrankiaiSDK package with build environment provided
GPL customizationYou can create your own custom, branded firmware and web page application by changing colours, logos, and other elements in our firmware to fit your or your clients’ needs
Package ManagerThe Package Manager is a service used to install additional software on the device
Location Tracking
GNSSGPS, GLONASS, BeiDou, Galileo and QZSS
KoordinatėsGNSS coordinates via WebUI, SMS, TAVL, RMS
NMEANMEA 0183
NTRIPNTRIP protocol (Networked Transport of RTCM via Internet Protocol)
Serverio programinė įrangaSupported server software TAVL, RMS
PoE (pasyvus)Possibility to power up through LAN1 port, not compatible with IEEE802.3af, 802.3at and 802.3bt standards, Mode B, 9 - 50 VDC
Energijos naudojimasIdle: < 3.9 W, Max: < 12.3 W
Fizinės sąsajos
Ethernet4 x RJ45 ports, 10/100/1000 Mbps
I/O’s1 x Digital Input, 1 x Digital Output on 4-pin power connector
Būsenos LED indikatoriai4 x WAN type LEDs, 2 x Mobile connection type, 5 x Mobile connection strength, 8 x LAN status, 1 x Power, 2 x 2.4G and 5G Wi-Fi
