IPsecIKEv1, IKEv2, with 5 encryption methods for IPsec (DES, 3DES, AES128, AES192, AES256)
GREGRE tunnel
PPTP, L2TPClient/Server instances can run simultaneously, L2TPv3 support
StunnelProxy designed to add TLS encryption functionality to existing clients and servers without any changes in the programs code
DMVPNMethod of building scalable IPsec VPNs
SSTPSSTP client instance support
ZeroTierZeroTier VPN client support
WireGuardWireGuard VPN client and server support
ID rangeRespond to one ID in range [1;255] or any
Nuotolinės prieigos leidimasAllow access through WAN
Pasirinktiniai registraiMODBUS TCP custom register block requests, which read/write to a file inside the router, and can be used to extend MODBUS TCP Slave functionality
Cloud of ThingsAllows monitoring of: Device data, Mobile data, Network info, Availability
ThingWorxAllows monitoring of: WAN Type, WAN IP, Mobile Operator Name, Mobile Signal Strength, Mobile Network Type
CumulocityAllows monitoring of: Device Model, Revision and Serial Number, WAN Type and IP, Mobile Cell ID, ICCID, IMEI, Connection Type, Operator, Signal Strength
Azure IoT HubCan send device IP, Number of bytes send/received, Temperature, PIN count to Azure IoT Hub server
CPUMediatek MIPS 24Kc 580 MHz
RAM128 MB, DDR2
FLASH saugykla16 MB, SPI Flash
WEB UIUpdate FW from file, check FW on server, configuration profiles, configuration backup, restore point
FOTAUpdate FW
RMSUpdate FW/configuration for multiple devices at once
Nustatymų įsiminimasUpdate FW without losing current configuration
Operacinė sistemaRutOS (OpenWrt based Linux OS)
KalbosBusybox shell, Lua, C, C++
Kūrėjo įrankiaiSDK package with build environment provided
Įvestis1 x Digital Input, 0 - 6 V detected as logic low, 8 - 30 V detected as logic high
Išvestis1 x Digital Output, Open collector output, max output 30 V, 300 mA
ĮvykiaiEmail, RMS, SMS
I/O jugglerAllows to set certain I/O conditions to initiate event
PoE (passive)Passive PoE over spare pairs. Possibility to power up through LAN port, not compatible with IEEE802.3af, 802.3at and 802.3bt standards, Mode B, LAN1 Port, 9 - 50 VDC
Energijos sunaudojimas< 2 W idle, < 7 W Max
Tinklas4 x RJ45 ports, 10/100 Mbps
I/O's1 x Digital Input, 1 x Digital Output on 4-pin power connector
LED indikatoriai1 x bi-color connection status LED, 5 x connection strength LEDs, 4 x LAN status LEDs, 1 x Power LED
