Dydis93 x 40 x 36.5 mm (3.7 x 1.6 x 1.4")
-
Svoris82 g (2.9 oz)
-
Korpuso medžiagaPolycarbonate, glass
-
MontavimasIn wall, gang box
-
Atsparumas oro sąlygomsIP55
-
Tinklo sąsaja(1) 10/100 MbE RJ45 port
-
JungiamumasBLE 4.1
-
Maitinimo metodasPoE
-
UL certificationsUL 294 Power-limited Class 2 PSU, UL 60950-1/62368-1 LPS/PS2 PSU
-
Palaikoma įtampos diapazonas48V DC
-
Maksimalus energijos suvartojimas5W
-
ES/EMP apsaugaAir: ±15kV, contact: ±8kV
-
JutikliaiProximity sensor
-
Garsiakalbis(1) 8 ohm, 0.7W
-
LEDSteady white: Pending adoption, Steady blue: Adopted, Alternating white/blue: Firmware updating, Strobing red: Emergency lockdown, Steady green: Emergency evacuation, (2) Rapid flashing blue: NFC credential authenticated, (2) Rapid flashing red: NFC credential authentication failed, Breathing blue: Ready to register NFC cards
-
Mygtukas(1) Factory-reset
-
NFC dažnis13.56 MHz
-
NFC skaitymo diapazonas< 30 mm
-
NFC standartaiISO 14443A, 14443B, 15693
-
NFC technologijaNFC Tag 1,2,3,4,5, MIFARE Classic, MIFAREPlus, MIFARE Ultralight, MIFARE DESFire
-
Darbo aplinkaOutdoor use
-
Darbinė aplinkos temperatūra-30 to 45° C (-22 to 113° F)
-
Aplinkos drėgmė5 to 90% noncondensing
-
Programinės įrangos informacijaThe software version can be checked at https://unifi.ui.com
-
UL 294 lygisDestructive attack: Level I, Line security: Level I, Endurance: Level I, Standby power: Level I
-
UL 294 pareiškimasCompliance with IEEE 802.3 specifications was not verified as part of UL 294
-
PoE kabelių reikalavimaiCat 5e minimum recommended, 26 AWG (patch cords), 24 AWG (horizontal/riser cable)
-
CAN/ULC-60839-11-1 GradeGrade I
