PPTP, L2TPClient/Server instances can run simultaneously, L2TPv3, L2TP over IPsec support
StunnelProxy designed to add TLS encryption functionality to existing clients and servers without any changes in the program’s code
DMVPNMethod of building scalable IPsec VPNs, Phase 2 and Phase 3 and Dual Hub support
SSTPSSTP client instance support
ZeroTierZeroTier VPN client support
WireGuardWireGuard VPN client and server support
TincTinc offers encryption, authentication and compression in it's tunnels. Client and server support.
TailscaleTailscale offers speed, stability, and simplicity over traditional VPNs. Encrypted point-to-point connections using the open source WireGuard protocol
OPC UA
Palaikomi režimaiClient, Server
Supported connection typesTCP
MODBUS
Palaikomi režimaiServer, Client
Supported connection typesTCP, RTU(RS232)
Pasirinktiniai registraiMODBUS TCP custom register block requests, which read/write to a file inside the router, and can be used to extend MODBUS TCP Client functionality
Data to serverExtract parameters from multiple sources and different protocols, and send them all to a single server; Custom LUA scripting, allowing scripts to utilize the router's Data to server feature
MQTT Gateway
Modbus MQTT GatewayAllows sending commands and receiving data from MODBUS Server through MQTT broker
DNP3
Palaikomi režimaiStation, Outstation
Supported connectionTCP, RTU(RS232)
DLMS/COSEM
DLMS SupportDLMS - standard protocol for utility meter data exchange
Palaikomi režimaiClient
Supported connection typesTCP, RTU(RS232)
COSEMAllows to scan meter COSEM objects for automatic detection and configuration
API
Teltonika Networks Web API (beta) supportExpand your device's possibilities by using a set of configurable API endpoints to retrieve or change data. For more information, please refer to this documentation: https://developers.teltonika-networks.com
Monitoring & Management
WEB UIHTTP/HTTPS, status, configuration, FW update, CLI, troubleshoot, multiple event log servers, firmware update availability notifications, event log, system log, kernel log, Internet status
FOTAFirmware update from server, automatic notification
SSHSSH (v1, v2)
El. paštasReceive email message status alerts of various services
SNMPSNMP (v1, v2, v3), SNMP Trap, Brute force protection
JSON-RPCManagement API over HTTP/HTTPS
MODBUSMODBUS TCP status/control
RMSTeltonika Remote Management System (RMS)
IoT platformos
ThingWorxUtility to interact with Thingworx cloud platform
Cumulocity - Cloud of ThingsAllows monitoring of: Device Model, Revision and Serial Number, WAN Type and IP. Has reboot and firmware upgrade actions
Azure IoT HubCan be configured with Data to Server to send all the available parameters to the cloud. Has Direct method support which allows to execute RutOS API calls on the IoT Hub. Also has Plug and Play integration with Device Provisioning Service that allows zero-touch device provisioning to IoT Hubs
AWS IoT CoreUtility to interact with the AWS cloud platform. Jobs Support: Call the device's API using AWS Jobs functionality
Sistemos Characteristikos
ProcesoriusMediatek, 580 MHz, MIPS 24KEc
RAM128 MB, DDR2
FLASH saugykla16 MB serial NOR flash
Nustatymai
WEB UIUpdate FW from file, check FW on server, configuration profiles, configuration backup
FOTAUpdate FW
RMSUpdate FW/configuration for multiple devices at once
Nustatymų įsiminimasUpdate FW without losing current configuration
Gamykloje nustatytų parametrų atstatymasA full factory reset restores all system settings, including the IP address, PIN, and user data to the default manufacturer's configuration
FIRMWARE CUSTOMISATION
Operacinė sistemaRutOS (OpenWrt based Linux OS)
KalbosBusybox shell (ash), Lua 5.1, C, C++
Kūrėjo įrankiaiSDK package with build environment provided
GPL customizationYou can create your own custom, branded firmware and web page application by changing colours, logos, and other elements in our firmware to fit your or your clients’ needs
Package ManagerThe Package Manager is a service used to install additional software on the device
Serial
RS232Terminal block connector: TX, RX, RTS, CTS
Serial functionsConsole, Serial over IP, Modem, MODBUS gateway, NTRIP Client
PoE (pasyvus)Passive PoE over spare pairs. Possibility to power up through LAN2 port, not compatible with IEEE802.3af, 802.3at and 802.3bt standards, Mode B, 9 - 30 VDC
Energijos suvartojimasIdle: < 1 W / Max: < 2 W
Fizinės sąsajos
Ethernet2 x RJ45 ports, 10/100 Mbps
Būsenos LED indikatoriai2 x LAN type LED, 1 x Power LED
