Prekės aprašymas
| - | Aliarmo temp. °C/°F |
Max. temp. |
Šarvas | Spalva |
Bendras diametras mm |
Sertifikatai |
| FT-68 | 68/155 | 45/113 | PVC | RED | 3.5 | FM/UL |
| FT-68 -R | 68/155 | 45/113 | Chemical Resistant Nylon |
BLACK | 4.5 | UL |
| FT-88 | 88/190 | 70/158 | PVC | WHITE | 3.5 | FM/UL |
| FT-88 -R | 88/190 | 70/158 | Chemical Resistant Nylon |
BLACK | 4.5 | UL |
| FT-105 | 105/220 | 85/185 | PVC | WHITE | 3.5 | FM/UL |
| FT-105 -R | 105/220 | 85/185 | Chemical Resistant Nylon |
BLACK | 4.5 | UL |
| FT-185 -R | 185/365 | 125/257 | Chemical Resistant Nylon |
RED | 3.5 | UL |
| Bendros specifikacijos | ||||||
| Laidininko varža | 0.190Ω/m or 0.0579Ω/FT @ 20C | |||||
| Max voltažas | 42Vdc or 30Vac | |||||
|
Dielektrinis pasipriešinimas (UL) |
500Vdc | |||||
| Tempimo jėga | 1700 N/mm2 | |||||
| Min. lenkimo spindulys | 75mm | |||||
| Svoris | 12Kg/500m | |||||
