Mobilus modulis 4G LTE Cat M1 up to 588 DL/1119 UL kbps, Cat NB2 up to 127 DL/158.5 UL kbps, Cat NB1 up to 32 DL/70 UL kbps (simultaneous operation of cellular and GNSS connectivity is not supported)
3GPP išleidimas Release 14
SIM switch 2 SIM cards, auto-switch cases: weak signal, data limit, SMS limit, on roaming, no network, network denied, data connection fail
Statusas IMSI, ICCID, operator, operator state, data connection state, network type, bandwidth, connected band, signal strength (RSSI), SINR, RSRP, RSRQ, EC/IO, RSCP, data sent/received, LAC, TAC, cell ID, ARFCN, UARFCN, EARFCN, MCC, MNC
SMS SMS status, SMS configuration, send/read SMS via HTTP POST/GET, EMAIL to SMS, SMS to EMAIL, SMS to HTTP, SMS to SMS, scheduled SMS, SMS autoreply, SMPP
Juodasis/baltasis sąrašas Operator black/white list (by country or separate operators)
Grupės valdymas Band lock, used band status display
SIM neaktyvumo apsaugos paslauga Idle SIM remains inactive until switch occurs, preventing data usage
SIM PIN kodo valdymas Setting, changing, disabling the SIM card's PIN
APN Auto APN
Tiltas Direct connection (bridge) between mobile ISP and device on LAN
Perleidimas Gateway assigns its mobile WAN IP address to another device on LAN
Tinklas 1 x ETH port, 10/100 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX crossover
Maršrutas Static, Dynamic (BGP, OSPF v2, RIP v1/v2, EIGRP, NHRP), Policy-based routing
Interneto protokolai TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSL v3, TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SNMP, MQTT, Wake On Lan (WOL), VXLAN
VoIP praėjimo parama H.323 and SIP-alg protocol NAT helpers
Ryšio stebėjimas Ping Reboot, Wget Reboot, Periodic Reboot, LCP and ICMP for link inspection
Ugniasienė Port forward, traffic rules, custom rules, TTL target customization
Ugniasienės būsenos puslapis View Firewall statistics, rules, and counters
Prievadų valdymas View, enable/disable device ports, auto-configure, change transmission speed
Tinklo topologija Visual network representation showing device connections
Viešosios interneto prieigos taškas Captive portal, Radius server, MAC authentication, SMS authorization, SSO authentication, internal/external landing page, walled garden, customizable hotspot themes
DHCP Static/dynamic IP allocation, DHCP relay, server configuration, status, static leases (MAC with wildcards)
QoS / išmanusis eilių valdymas (SQM) Traffic priority by source/destination, service, protocol or port, WMM, 802.11e
DDNS Supports over 25 providers; manual configuration possible
DNS per HTTPS Proxy for secure DNS resolution
Tinklo atsarginės kopijos VRRP, Wired options, automatic Failover, Mobile
SSHFS Mount remote file system via SSH protocol
Eismo valdymas Real-time monitoring, wireless signal charts, traffic usage history
Autentifikavimas Pre-shared key, digital certificates, X.509, TACACS+, RADIUS users authentication, IP & login attempts block, time-based login blocking
Ugniasienė Pre-configured rules via WebUI, unlimited configuration via CLI, DMZ, NAT, NAT-T
Įsilaužimo prevencija DDOS, port scan prevention (SYN-FIN, SYN-RST, X-mas, NULL flags, FIN scan)
VLAN Tag-based VLAN separation
Mobiliųjų kvotų kontrolė Data limit, customizable period, warning limits, phone number
WEB filtras Blacklist/Whitelist for site control
Prieigos kontrolė SSH, Web interface, CLI, Telnet access control
SSL sertifikatas Let's Encrypt support
OpenVPN Multiple clients/servers, 27 encryption methods (DES, AES, RC2, BF-CBC, CAST5)
IPsec XFRM, IKEv1/IKEv2, 14 encryption methods (3DES, DES, AES128-256, GCM variants)
GRE GRE tunnel, GRE over IPsec
PPTP, L2TP Client/Server instances can run simultaneously, L2TPv3, L2TP over IPsec
Stunnel Add TLS encryption to existing clients/servers without code changes
DMVPN IPsec VPNs, Phase 2/3, Dual Hub support
SSTP SSTP client instance support
ZeroTier ZeroTier VPN client support
WireGuard WireGuard VPN client and server
Tinc Encryption, authentication, compression for tunnels; client/server
BACNET Router mode, RS485, TCP support
OPC UA Client/Server modes, TCP support
MODBUS Server/Client, RS232, RS485, TCP, custom register block requests, multiple data formats
DNP3 Station/Outstation modes, RS232, RS485, TCP
DLMS Client mode, RS232, RS485, TCP
Teltonika API Configurable API endpoints for data retrieval or modification
Stebėjimas HTTP/HTTPS, status, configuration, FW update, CLI, troubleshoot, event logs
FOTA Firmware updates from server, automatic notifications
SSH SSH (v1, v2)
SMS Manage SMS status/configuration, HTTP POST/GET control
Call Mobile data control, output toggling, reboot
TR-069 OpenACS, EasyCwmp, ACSLite, tGem, etc.
MQTT MQTT Broker/Publisher
SNMP SNMP (v1, v2, v3), SNMP Trap, brute force protection
JSON-RPC Management API over HTTP/HTTPS
RMS Teltonika Remote Management System (RMS)
ThingWorx Monitor WAN type, IP, signal strength, and more
Kumuliškumas Device model, serial number, IP, mobile cell ID, signal strength, and more
Azure IoT Hub Data to server, direct methods for RutOS API calls
Sistemos CPU Mediatek, 580 MHz, MIPS 24KEc
RAM 128 MB
FLASH saugykla 16 MB
Operacinė sistema RutOS (OpenWrt based Linux OS)
Kūrėjo įrankiai SDK, Busybox shell, Lua, C, C++
Pritaikymas GPL customization (branding, colors, logos), Package Manager
GNSS GPS, GLONASS, BeiDou, Galileo (in development)
Koordinatės WebUI, SMS, TAVL, RMS
NMEA NMEA 0183
NTRIP Networked Transport of RTCM via Internet Protocol
Geotvoros Multiple configurable zones
RS232 Terminal block: TX, RX, RTS, CTS
RS485 Terminal block: D+, D-, R+, R-
I/O jungiklis Set I/O conditions to initiate events
Sistemos parametrai 2-pin in 16-pin industrial terminal block, 9 – 30 VDC, surge/reverse polarity protection
Energijos sunaudojimas Idle: <2 W, Max: <3.5 W
Fizinės sąsajos 1 x RJ45, 3 x configurable digital I/O, 2 SIM slots, SMA connectors for LTE/GNSS, reset button
Korpusas Aluminium housing
Dydis 83 x 25 x 74.2 mm
Svoris 165 g
Montavimas DIN rail, wall mount, flat surface (kit required)
Darbinė temperatūra -40 °C to 75 °C
Drėgmė 10% to 90% non-condensing
Įleidimo apsaugos reitingas IP30
