Procesoriaus informacija1.3 GHz Dual-Core, ARM Cortex-A53
Flash/ROM atmintis128 MB (1 Gbit) NAND
DDR/RAM atmintis256 MB (2 Gbit) DDR3
5 GHz Wi-Fi Speed2402 Mbps
2.4 GHz „Wi-Fi“ greitis574 Mbps
5 GHz Wi-Fi Streams2T2R (2×2 MIMO)
2.4 GHz „Wi-Fi“ srautai2T2R (2×2 MIMO)
„Wi-Fi“ antenos5× Internal
5 GHz antenos stiprinimas max5.1 dBi
2.4 GHz antenos stiprinimas max4.2 dBi
FEM arba PA/LNA5 GHz: 3× Internal, 2.4 GHz: 2× Internal
Spindulio formavimasTrue
Veikimo nuotolisMax: 220 m (722 ft); Indoor WiFi range varies depending on the layout and wall materials. See Wall Performance spec for placement suggestions.
Sienų pralaidumasTwo wooden walls with thickness < 10 cm (4''), One concrete wall with thickness < 20 cm (7'') or two concrete walls with thickness < 10 cm (4'')
Indoor Coverage Reference2 Pack: 200 m² (2150 sq ft), 3 Pack: 270 m² (2900 sq ft); Applied to wireless backhaul situation. Place in the center of each floor, with a maximum of three obstacles to each room.
2.5G RJ45 Ports1
Gigabit RJ45 Ports1
Eterneto pastabosThe 2.5G port is WAN port, the Gigabit port is LAN port
LED indikatoriaiSystem, Speed/Link/ACT of Ethernet Port
